C-Frame Single Crank - Single Point Press
With high rigidity design in machine frame, the machine body is welded of quality steel sheet and treated by tension elimination, improve stability and reliability of the mechanical precision. C-Frame Single Crank Presses are widely used in electronics, communications, computers, household appliances, transport (automobiles, motorcycles, bicycles), metal parts stamping and forming etc..
| Parameter | Unit |
| Nominal capacity | tf |
| Stroke | mm |
| Variable speed stroke | s.p.m |
| Die setting height | mm |
| Die height adjustment | mm |
| Throat depth | mm |
| Distance between uprights | mm |
| Table size | mm |
| Bottom size of slide | mm |
| Power of motor | kW |
| Overall dimension(LxWxH) | mm |
| Weight | kg |
EPMC-125A 125 18.6-150 45-60 400 90 320 600 1100x630 700x400 15/11 2150x1300x3150 10500
