| Paraméter | Egység |
| Asztalméret | mm |
| X tengely lökete | mm |
| Y tengely lökete | mm |
| Z tengely lökete | mm |
| Munkadarab méret | mm |
| Munkadarab tömeg | kg |
| Max. elektróda tömeg | kg |
| Munkaasztal és Z-felfogólap távolsága | mm |
| Alapfelszereltség | |
| Max. megmunkálási áramerősség | A |
| Min. elektróda kopás | % |
| Kijelző | inch |
| Programozható tengely | |
| Gépméretek (HxSzxM) | m |
| Géptömeg | kg |
NOVIFORM 380E 600x400 380 250 250 800x500x320 1000 70 250-500 380V±10% / 50(60) 64 0.03 15 XYZ 1650x1500x1975 1800
CNC CONTROL SYSTEM
 |
 |
 |
|
3 pages of functional screens consisted of Setup, Erosion, Diagnostic provide very friendly man-machine interface
Real-timely multi-tasking control software makes it possible to do preparations for next jobs during erosion
The flexible NC programming system can meet the needs both for beginners and experienced operators.
With orbit function, machine can finish various kinds of EDM machining conveniently.
With powerful CNC function, edge Find,Center Find, Automatically.
With RS-232 communication interface and USB interface, the machine can exchange datum with programming
computer or control center conveniently.
|
||
Waterproof keyboard with stainless steel keys
Quick flushing and submerging modes possible
Fast and easy filling, flushing and draining of tank
Double locking door system(mechanical and magnetic)
Special design leak proof rubber lining
Large worktable with capacity up to 1000kg
Double filtration system
An ergonomic remote control panel is provided for fast positioning by the operator
Convenient snap-in snap-out hose system
